Antibody Product Overview
| ELK.No | ES5462 |
| Product name | TIMAP rabbit pAb |
| Reactivity | Human;Mouse |
| Applications | WB;IHC |
| Other name | PPP1R16B; ANKRD4; KIAA0823; Protein phosphatase 1 regulatory inhibitor subunit 16B; Ankyrin repeat domain-containing protein 4; CAAX box protein TIMAP; TGF-beta-inhibited membrane-associated protein; hTIMAP |
| Size | 50μL |
| Unit price ($) | 148 |
| Human gene ID | 26051 |
| Human Swiss-Prot | Q96T49 |
| Source | Rabbit |
| Isotype | IgG |
| Target | TIMAP |
| Fields | |
| Gene name | PPP1R16B |
| Protein name | Protein phosphatase 1 regulatory inhibitor subunit 16B |
| Human gene link | View Human Gene |
| Human Swiss link | View Human Swiss-Prot |
| Mouse gene ID | 228852 |
| Mouse gene link | View Mouse Gene |
| Mouse Swiss-Prot | Q8VHQ3 |
| Mouse Swiss link | View Mouse Swiss-Prot |
| Rat gene ID | |
| Rat gene link | |
| Rat Swiss-Prot | |
| Rat Swiss link | |
| Immunogen | The antiserum was produced against synthesized peptide derived from human PPP1R16B. AA range:364-413 |
| Specificity | TIMAP Polyclonal Antibody detects endogenous levels of TIMAP protein. |
| Formulation | Liquid in PBS containing 50% glycerol, 0.5% BSA and 0.02% sodium azide. |
| Clonality | Polyclonal |
| Dilution | WB 1:500-2000;IHC-p 1:50-300 |
| Purification | The antibody was affinity-purified from rabbit antiserum by affinity-chromatography using epitope-specific immunogen. |
| Concentration | 1 mg/ml |
| Storage stability | -20°C/1 year |
| Molecular Weight (Da) | |
| Observed band (KD) | 64kD |
| Background | The protein encoded by this gene is membrane-associated and contains five ankyrin repeats, a protein phosphatase-1-interacting domain, and a carboxy-terminal CAAX box domain. Synthesis of the encoded protein is inhibited by transforming growth factor beta-1. The protein may bind to the membrane through its CAAX box domain and may act as a signaling molecule through interaction with protein phosphatase-1. Alternative splicing results in multiple transcript variants encoding different isoforms that may undergo similar processing to generate mature protein. [provided by RefSeq, Sep 2015], |
| Function | function:May be a downstream target for TGF-beta1 signaling cascade in endothelial cells.,induction:Inhibited by TGF-beta1.,similarity:Contains 5 ANK repeats.,subunit:Binds PP1.,tissue specificity:Highly expressed in vascular endothelium, CNS, lung, spleen, kidney and testis., |
| Subcellular location | Cell membrane . Cell membrane ; Lipid-anchor . Nucleus . Cell projection . Colocalizes with RPSA/LAMR1 in the cell membrane (PubMed:16263087). Localizes to the perinuclear region (By similarity). Colocalizes with PTEN at the tip of EC projections (PubMed:25007873). . |
| Expression | Brain, |
Additional Images
No image
Western blot analysis of lysates from mouse brain, using PPP1R16B Antibody. The lane on the right is blocked with the synthesized peptide.
No image
Immunohistochemical analysis of paraffin-embedded human Colon cancer. 1, Antibody was diluted at 1:200(4° overnight). 2, Tris-EDTA,pH9.0 was used for antigen retrieval. 3,Secondary antibody was diluted at 1:200(room temperature, 45min).
